vehicle tachograph gps speed limiter device QTM600B

Description

Descriptioin of Vehicle Tachograph Data Recorder QTM600B

Digital Tachograph gps tracker is the device that records driving times and rest periods as well as other works. The purpose of the tachograph is to prevent fatigue driving, moreover,  it can guarantee fair competition and road safety. But first and formost, it is a digital tachograph with strong data recording function.

the main functions of qTM600B is as bellow

1. record datas
2. LCD screen and IC Card driver identification
3. a built-in printer (a single click to print 15-minute speed report)
4. large capacity data storage (128GB)
5. Wider range of vehicle interfaces (RS232)
6. Driver Management with IC Card
7. Power Failure Protection to ensure data records complete
8. Fatigue driving alert to improve fleet safety

Why we need QTM600B

In recent years, due to road safty, many countries have introduces relevant regulations. In China, for example, the regulation (national standard GB/T 19056) is mandatory to install a tachograph in new vehicles having a mass of more than 3,5 tonnes when they are intended for the transport of goods, or new vehicles carrying more than 9 persons including the driver, when they are intended for the transport of passengers.

Digital tachograph gps tracker are able to record and store the activity of the driver and the co-driver in an accurate and secure manner,  thanks to the implementation of forefront technology and strong anti-tampering measures. The driver must insert into the tachograph a personal card incorporating a microchip before starting to drive. This personal card stores the driving activity from the driver for at least 28 days and ensures that the information can be easily retrieved by inspection authorities.

Since 15 June 2019 a new generation of tachographs, so called smart tachographs, are being installed in newly registered trucks and buses. The smart tachograph features the same functionalities as previous generations of the digital tachograph, complemented with additional communication tools, such as GNSS positioning and transmission of real-time information to enforcement authorities by means of a short-range communication channel. It also incorporates enhanced anti-tampering measures such as encryption keys generated with the most advanced algorithms.

Parameter of Vehicle GPS Tracker QTM600B

Model	QTM600B
Voltage	9~36V
Current	70mA@12V/24V
Print voltage	9~36V
Print current	390mA~1200mA
Power consumption	0.84W
Speed range	0~255km/h
Speed accuracy	0.5km/h
Size	18.5cm×11cm×5cm
Case color	Black
CPU chip processor	STM32F105
Main frequency	72MHZ
External storage capacity	128GB
CPU Flash Capacity	32MB
Temperature	-20~70 temperature
Dot-matrix LCD Screen	240×32
Print format	Thermal print
RTC	DS1307 Chip offered
GPS Chipe	Ublox-7
GSM/4G	Un-support



Functions of Vehicle GPS Tracker speed limiter

Tired of managing many devices and software platforms? Quectrix digital tachograph gps tracker speed limiter QTM600B is a all-round protection device for your fleet management.  First and foremost, it is a data recorder device.

• Digital Tachograph Function

What it is:  Accurately records driving time, rest periods, and other activities as required by law.

Benefit to you: Stay 100% obey to law during inspections. What is to say, avoid heavy fines, and manage driver hours efficiently. Simplify your work with automatic data download function.

• Live GPS Tracker Function

What it is: Provide real-time vehicle location information on online map via 4G/LTE signal.

Benefit to you:  Imporove customer service with precise ETAs, reduce unauthorized vehicle use, moreover, recover stolen vehicles faster.

• Programmable speed limiter

What it is:  trigger alert when the vehicle is over the pre-set speed limit.

Benefit to you:  to get a safer driving habits, reduce the speed-related accidents, lower fuel consumption and decrease wear-and-tear on vehicles.

• Fleet Management Platform

What it is: view all your data in online tracking platform by app and web.

Benefit to you: Not only lower costs but also improve operational efficiency.  What’s more, we can download datas to do some analysis accordingly.

Target customers of vehicle tachograph gps speed limiter device QTM600B

1. The product best suited for:
2. logistics fleets
3. passenger transport companies
4. public transportation systems
5. Hazardous materials transport vehicles

FAQ

Q: Does the QTM600B support 4G?

A: According to the hardware specifications, this device does not include 4G Modules. It is a professinal data logger that collects vehicle data via the CANbus, speed sensors and other sources.

Q: How do I export and print data?

A: You can download a 360-hour speed report via the USB port or print a 15-minute speed report directly by pressing the print button on the device panel.

Q: What vehicles voltages does the device support?

A: It supports a wide input voltage range of 6-36V, making it compatible with various commercial vehicles operating on 12V and 24V.

Q: Do you have any other GPS speed limiters?

A: Yes, If you need remote GPS tracking capabilities, please refer to our ITMS Nano or GV100S products.
